API Reference

The Stelltron backend exposes a REST API built on Go/Gin. All protected endpoints require a Bearer JWT token in the Authorization header.

Base URL:

  • Local: http://localhost:8080
  • Production: https://los-tecnicos-backend.onrender.com

Authentication​

POST /api/v1/auth/signup​

Register a new user by verifying their Stellar wallet signature.

Request:

{
  "wallet_address": "GCKFBEIYTKP4BOFPNR4MXKCDQHM3BLFBE4MIFP7GHPDMMCQKWMQ7WT",
  "signature": "<base64-encoded Ed25519 signature>"
}

The signature must be over the message "los-tecnicos-auth" using the Stellar message prefix:

SHA256("Stellar Signed Message:\n" + "los-tecnicos-auth")

Response 201:

{
  "id": "GCKFBEIYTKP4...",
  "wallet_address": "GCKFBEIYTKP4...",
  "role": "Recipient",
  "kyc_status": "pending",
  "created_at": "2026-02-23T09:56:48Z"
}

Response 200: Returns existing user if wallet already registered.

POST /api/v1/auth/login​

Authenticate an existing user and return JWT tokens.

Request: Same as signup.

Response 200:

{
  "access_token": "<JWT, 15-minute TTL>",
  "refresh_token": "<UUID, 7-day TTL>"
}

POST /api/v1/auth/refresh​

Exchange a refresh token for a new access token.

Request:

{
  "refresh_token": "<UUID>"
}

Response 200:

{
  "access_token": "<new JWT>"
}

GET /api/v1/auth/me​

Returns the authenticated user's profile.

Headers: Authorization: Bearer <access_token>

Response 200:

{
  "id": "GCKFBEIYTKP4...",
  "wallet_address": "GCKFBEIYTKP4...",
  "role": "Donor",
  "location": "",
  "kyc_status": "pending",
  "created_at": "2026-02-23T09:56:48Z"
}

Market​

All market routes require Authorization: Bearer <access_token>.

GET /api/v1/market/orders​

Returns all open (status = "Created") energy orders.

Response 200:

[
  {
    "id": "550e8400-e29b-41d4-a716-446655440000",
    "user_id": "GCKFBEIY...",
    "type": "sell",
    "kwh_amount": 0.5,
    "token_price": 9.02,
    "status": "Created",
    "created_at": "2026-02-23T09:00:00Z"
  }
]

POST /api/v1/market/order/create​

Create a buy or sell order.

Request:

{
  "type": "buy",
  "kwh_amount": 0.5,
  "token_price": 10.0
}

Role enforcement:

  • sell orders: user must be Donor or NetworkNodeOperator
  • If role is Recipient, automatically promoted to Donor on first sell

Response 201:

{
  "id": "550e8400-...",
  "user_id": "GCKFBEIY...",
  "type": "buy",
  "kwh_amount": 0.5,
  "token_price": 10.0,
  "status": "Created",
  "created_at": "2026-02-23T09:10:00Z"
}

POST /api/v1/market/order/cancel​

Cancel an open order owned by the authenticated user.

Request:

{
  "order_id": "550e8400-..."
}

Response 200:

{
  "message": "Order cancelled successfully"
}

GET /api/v1/market/price​

Returns the current dynamic market price with full factor breakdown.

Response 200:

{
  "price": 9.02,
  "supply": 7,
  "demand": 5,
  "timestamp": "2026-02-23T09:10:00Z",
  "breakdown": {
    "base_price": 5.0,
    "f_sd": 0.927,
    "f_soc": 1.061,
    "f_dist": 1.2,
    "f_time": 1.15,
    "f_quality": 1.08,
    "final_price": 9.02
  }
}

GET /api/v1/market/history​

Returns up to 50 most recent completed trade prices for charting.

Response 200:

[
  {
    "price": 8.75,
    "timestamp": "09:01"
  },
  {
    "price": 9.10,
    "timestamp": "09:04"
  }
]

IoT (Hardware Endpoints)​

These endpoints are called by the Raspberry Pi without authentication.

POST /iot/ping​

Receives the Pi's periodic telemetry update.

Request (heartbeat):

{
  "device_id": "rpi-4b-prod-01",
  "status": "heartbeat"
}

Request (node data):

{
  "device_id": "rpi-4b-prod-01",
  "voltage": 3.921,
  "battery_level": 72.4,
  "state": "IDLE",
  "source": "rpi_energy_grid",
  "timestamp": "2026-02-23T09:56:48Z",
  "connected_nodes_count": 2,
  "connected_nodes": [
    {"uid": "NODE_A", "voltage": 3.921},
    {"uid": "NODE_B", "voltage": 3.610}
  ],
  "nodes_detail": [
    {
      "uid": "NODE_A",
      "ip": "192.168.1.101",
      "voltage": 3.921,
      "soc": 72.4,
      "state": "IDLE"
    }
  ]
}

Response 200:

{
  "status": "received",
  "type": "node_data",
  "updated": true,
  "commands": [
    {"node_id": "NODE_A", "action": "discharge"},
    {"node_id": "NODE_B", "action": "charge"}
  ]
}

POST /iot/cmd​

The Pi sends its current node states and receives scheduling commands.

Request:

{
  "device_id": "rpi-4b-prod-01",
  "nodes": [
    {"uid": "NODE_A", "voltage": 3.921, "soc": 72.4, "state": "IDLE"},
    {"uid": "NODE_B", "voltage": 3.610, "soc": 28.1, "state": "IDLE"}
  ]
}

Maximum 5 nodes per request.

Response 200:

{
  "commands": [
    {
      "node_id": "NODE_A",
      "action": "discharge",
      "reason": "manual transfer command (discharge)"
    },
    {
      "node_id": "NODE_B",
      "action": "charge",
      "reason": "manual transfer command (charge)"
    }
  ],
  "grid_summary": {
    "avg_soc": 50.25,
    "discharging_nodes": 1,
    "charging_nodes": 1,
    "idle_nodes": 0
  }
}

GET /iot/nodes/:device_id​

Returns all NodeDetail records for a given device.

Response 200: Array of node detail objects.

POST /iot/transfer​

Manually initiate an energy transfer between two nodes.

Request:

{
  "device_id": "rpi-4b-prod-01",
  "sender_node_uid": "NODE_A",
  "receiver_node_uid": "NODE_B"
}

Writes discharge command for sender and charge command for receiver in schedule_commands.

POST /iot/transfer/stop​

Stop an active transfer and return all nodes to idle.

Request:

{
  "device_id": "rpi-4b-prod-01"
}

POST /iot/energy/report​

Pi reports a completed physical energy transfer for token minting.

Request:

{
  "device_id": "rpi-4b-prod-01",
  "sender_uid": "NODE_A",
  "receiver_uid": "NODE_B",
  "kwh_transferred": 0.5,
  "duration_seconds": 1800,
  "avg_voltage": 3.92,
  "avg_current": 0.27
}

Allowed range: kwh_transferred in [0.001, 10.0].

Response 200:

{
  "status": "minted",
  "tokens_minted": 533.3,
  "quality_factor": 1.067,
  "sell_order_id": "auto_sell_42",
  "dynamic_price": 9.02,
  "co2_saved_kg": 0.41,
  "carbon_credit": 0.0205,
  "tx_hash": "mint_20260223_095648",
  "message": "533.30 LT tokens minted for 0.5000 kWh → auto-listed at 9.02 XLM/kWh"
}

GET /iot/events​

Server-Sent Events stream. Frontend connects here for real-time grid updates.

Response: text/event-stream

data: {"timestamp":"2026-02-23T09:56:48Z","type":"heartbeat","payload":{"device_id":"rpi-4b-prod-01","status":"heartbeat"}}

data: {"timestamp":"2026-02-23T09:56:53Z","type":"node_data","payload":{...}}

data: {"timestamp":"2026-02-23T09:57:00Z","type":"schedule","payload":{"commands":[...],"grid_summary":{...}}}

data: {"timestamp":"2026-02-23T09:57:30Z","type":"energy_mint","payload":{"tokens_minted":533.3,...}}

IoT Device Management (Protected)​

GET /api/v1/iot/devices​

Returns all IoT devices registered to the authenticated user.

POST /api/v1/iot/device/register​

Register a new device for the authenticated user.

Request:

{
  "device_type": "raspi",
  "location": "Bangalore, India"
}

Network Nodes (Protected)​

GET /api/v1/network/nodes​

Returns all registered network nodes.

POST /api/v1/network/node/register​

Register as a network node operator. Updates user role to NetworkNodeOperator.

Request:

{
  "location": "Bangalore, India"
}

DePIN​

POST /api/v1/depin/register​

Register a hardware device in the DePIN network.

Request:

{
  "device_id": "rpi-4b-prod-01",
  "operator_wallet": "GCKFBEIY...",
  "hardware_type": "rpi4b",
  "firmware_version": "1.2.0"
}

POST /api/v1/depin/heartbeat​

Report node uptime and route activity. Triggers reward calculation.

Request:

{
  "device_id": "rpi-4b-prod-01",
  "kwh_routed": 0.5
}

GET /api/v1/depin/nodes​

Returns all registered DePIN nodes.

GET /api/v1/depin/stats​

Returns network-wide DePIN statistics including total nodes, average reliability, and network health status.

DeFi​

POST /api/v1/defi/pool/stake​

Stake LT tokens in the liquidity pool.

Request:

{
  "user_id": "GCKFBEIY...",
  "amount": 1000.0
}

POST /api/v1/defi/pool/unstake​

Withdraw tokens plus accrued yield.

Request:

{
  "stake_id": 42
}

GET /api/v1/defi/pool/stats​

Returns TVL, current APY, and pool utilization.

Response 200:

{
  "total_staked": 50000.0,
  "active_stakers": 12,
  "current_apy": 5.1,
  "pool_utilization": 0.38
}

POST /api/v1/defi/flash-loan​

Borrow tokens for up to 5 minutes.

Request:

{
  "borrower_id": "GCKFBEIY...",
  "kwh_borrowed": 5.0,
  "token_collateral": 7500.0
}

POST /api/v1/defi/flash-loan/repay​

Repay an active flash loan.

Request:

{
  "loan_id": 7
}

GET /api/v1/defi/yield/history​

Returns yield history records.

Transparency Ledger (Public)​

All ledger endpoints are unauthenticated for public verifiability.

GET /api/v1/ledger/overview​

System-wide statistics: total minted, total burned, circulating supply, total CO₂ saved.

GET /api/v1/ledger/transactions​

All completed trades with blockchain hashes.

GET /api/v1/ledger/mints​

All token minting events with source device and quality factor.

GET /api/v1/ledger/burns​

All token burn events with reason and trade association.

GET /api/v1/ledger/carbon​

All carbon credit records with CO₂ saved and credit value.

GET /api/v1/ledger/price-history​

Historical price calculations with all factor breakdowns.

Analytics​

GET /api/v1/analytics/dashboard​

Public market statistics.

Response 200:

{
  "total_users": 247,
  "total_iot_devices": 3,
  "total_network_nodes": 12,
  "total_energy_traded": 148.5,
  "active_orders": 8
}

GET /api/v1/analytics/transactions (Protected)​

Returns the authenticated user's transaction history (as donor or recipient).

Token Supply​

GET /api/v1/tokens/supply​

Response 200:

{
  "total_minted": 250000.0,
  "total_burned": 240000.0,
  "circulating_supply": 10000.0,
  "total_mint_events": 500,
  "token_name": "LT (Los Técnicos Energy Token)",
  "ratio": "1 kWh = 1000 LT"
}

WebSocket​

GET /ws/market​

WebSocket connection for real-time market data. Currently sends a welcome message on connect and remains open. Future: live price tick broadcast.

Route Summary​

Total: 44 endpoints — 30 public, 10 protected.

Error Responses​

All endpoints return errors in a consistent format:

{
  "error": "Human-readable error message"
}
HTTP StatusWhen
400Bad JSON, validation failure, invalid parameters
401Missing or invalid JWT, invalid wallet signature
403Insufficient role for action (e.g., Recipient trying to sell)
404Resource not found
500Database error, Soroban call failure

Rate Limiting​

Redis-backed rate limiting: 100 requests per minute per IP address.
